Outdoor series

Wind- and weather-resistant

Outside home

Sielaff's outdoor variants tested by an independent institute, bear the GS mark and impress at first glance in terms of design and technology. These machine variants are ideally equipped, fulfil the requirements of protection class IP24 for the outdoor area and are weather-resistant up to -20°C.

Especially high sales locations in public areas with a lot of walk-in customers and highly frequented places require correspondingly robust machine features. The High-Security version guarantees even more effective protection against theft, vandalism and tampering.

Outdoor series variants

Robimat XL

Introduction

  • Protection class: IP24
  • Winter resistant up to -20°C
  • Version for locations exposed to vandalism
  • Anti-vandalism panel
  • Rain shield and weatherproof protection
  • Coin insert slide and coin return drum
  • Reinforced locking lever protection
  • Security frame with side lock
  • Laminated safety glass panel with UV filter
  • Residual current circuit breaker
  • High performance chiller unit with heater with "frost monitoring function", so that the internal temperature is held above 0°C
  • Rear panel offers advertising opportunity

Dimensions: 1,856 x 1,178 x 1,210 mm (height x width x depth)*
Weight: approx. 459 kg (without products, depending on the layout)
Electrical connection values: 220 - 230 V / 50 Hz / min. 10 A
Power consumption: 400 - 750 W (varies depending on the type of chiller unit)
Protection class: IP24

*Deviations in the housing dimensions are possible due to add-on parts and accessories.

Operator panel

  • RO = Operator panel RAL painted

  • Anti-vandalism panel
  • Rain shield and weatherproof protection
  • Coin insert slide and coin return drum
  • Reinforced locking lever protection
  • Security frame with side lock
  • Laminated safety glass panel with UV filter
  • Residual current circuit breaker
  • High performance chiller unit with heater with "frost monitoring function", so that the internal temperature is held above 0°C
  • Rear panel offers advertising opportunity
FS 2020

Introduction

  • Rain shield and weatherproof protection
  • Protection class: IP24
  • Weather-resistant up to -20°C
  • Residual current circuit breaker
  • High-performance chiller unit with heater with "frost monitoring function": the internal temperature is held above 0 °C
  • Rear panel (advertising opportunity)
  • Front and side kickplates
  • Version suitable for locations exposed to vandalism
  • Security frame with additional lock
  • Anti-vandalism panel
  • Coin insert slide and coin return drum
  • Reinforced locking lever protection
  • Metal keypad

Dimensions: 1,830 x 990 x 900 mm (height x width x depth)*
Weight: Approx. 460 kg (without products, depending on the layout)
Electrical connection values: 220-230 V / 50/60 Hz / min. 10 A
Output: 850 W (varies depending on the type of chiller unit)

*Deviations in the housing dimensions are possible due to add-on parts and accessories.

Operator panel

  • EC = Operator panel made from stainless steel
  • RB = Operator panel RAL painted

Cabinet colors

  • Pure white (RAL 9010)
  • White aluminum (RAL 9006)
  • Jet black (RAL 9005)
SÜ 2020

Introduction

  • Only SÜ 2020 and SoftDrop
  • Rain shield and weatherproof protection
  • Protection class: IP24
  • Weather-resistant up to -20°C
  • Residual current circuit breaker
  • High-performance chiller unit with heater ("frost monitoring function", the internal temperature is held above 0 °C)
  • Rear panel (advertising oportunity)
  • Front and side kickplates
  • Variant suitable for locations exposed to vandalism
  • Security protection frame with side lock
  • Anti-vandalism panel
  • Coin insert slide and coin return drum
  • Reinforced locking lever protection
  • Metal keypad

Dimensions: 1,855 x 1,022 x 900 mm (height x width x depth)*
Weight: Approx. 370 kg (without products, depending on the layout)
Electrical connection values: 220 - 230 V / 50/60 Hz / min. 10 A
Output: 670 W (varies depending on the chiller unit)

* Deviations of the housing dimensionsare possible due to add-on parts and accessories.

Operator panel

  • EC = Operator panel made from stainless steel
  • RB = Operator panel RAL painted

Cabinet colors

  • Pure white (RAL 9010)
  • White aluminum (RAL 9006)
  • Jet black (RAL 9005)

  • Multiflex-pusher:multiflex pushers for easier dispense of drink cartons up to 1L or similar non-food items
  • Light barrier: To monitor product dispense once the ordering process has been triggered
  • Reinforced shelf: For products with a total weight of more than 15 kg
  • Ingress protection
SiOne

Introduction

  • Rain shield
  • Flap in front of product acceptance unit
  • Security frame with side lock
  • Rear panel (advertising opportunity)
  • Residual current circuit breaker
  • Heater

Dimensions: 1,861 x 1,055 x 1,000 mm (height x width x depth incl. roof shelf)*
Weight: 170 kg
Acceptance speed: Up to 30 empties per minute
Capacity: Approx. 600 bottles (0.5 l PET) or approx. 700 cans
Electrical connection values: 220 - 230 V / 50/60 Hz /min. 10 A

*Deviations in the housing dimensions are possible due to add-on parts and accessories.

Operator panel

  • EC = Operator panel made from stainless steel
  • RB = Operator panel RAL painted

Cabinet colours

  • Pure white (RAL 9010)
  • White aluminum (RAL 9006)
  • Jet black (RAL 9005)

Door colours

  • Pure white (RAL 9010)
  • White aluminum (RAL 9006)
  • Jet black (RAL 9005)

  • Second coin hopper
  • Separation into two fractions
  • Roller container
  • Receipt printer
  • Ingress protection
  • Anti-duping device
  • Product recognition (cup return possible with or without barcode)

An overview of the benefits

For outdoor use

For outdoor use

For outdoor use

  • Wear the GS-logo
  • Complies with the requirements of protection class IP 24 for the outdoor area
  • Weather resistant up to -20°C
  • Reliable, low-maintenance and with a long service life
Made in Germany

Made in Germany

Made in Germany

  • Production on site in Germany
  • Concept, development, production and assembly of our machines come “from a single source”
  • ISO-certification as strict quality control of all processes in the production process guarantees a consistent quality assurance.
  • State-of-the-art manufacture
High level of security

High level of security

High level of security

  • Suitable for places with high sales in public areas frequented by walk-in customers, such as schools, train stations and airports.
  • The High-Security version guarantees effective protection against theft, vandalism and tampering
Reverse vending

Reverse vending

Reverse vending

  • We take a holistic approach to looking at things: Those who sell should also take back. With the SiOne EO, customers can now return empties even in the outdoor areas
  • Easy to use and fast processing speed
